Analog Devices Inc. AD8421TRMZ-EP-R7

Part No.:: AD8421TRMZ-EP-R7

Manufacturer:: Analog Devices Inc.

Package:: 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)

Datasheet:: AD8421TRMZ-EP-R7.pdf

Description:: IC INST AMP 1 CIRCUIT 8MSOP

In Stock:: 2638

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD8421TRMZ-EP-R7 Specifications

Package/Case:
8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Active
AmplifierType:
Instrumentation
NumberofCircuits:
1
OutputType:
-
SlewRate:
35V/µs
GainBandwidthProduct:
-
-3dbBandwidth:
10 MHz
Current-InputBias:
1 nA
Voltage-InputOffset:
70 µV
Current-Supply:
2mA
Current-Output/Channel:
65 mA
Voltage-SupplySpan(Min):
5 V
Voltage-SupplySpan(Max):
36 V
OperatingTemperature:
-55°C ~ 125°C
MountingType:
Surface Mount
