Analog Devices Inc. AD826ARZ

Part No.:: AD826ARZ

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: AD826ARZ.pdf

Description:: IC VOLTAGE FEEDBACK 2 CIRC 8SOIC

In Stock:: 2941

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD826ARZ Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Bulk,Tube
Series:
-
ProductStatus:
Active
AmplifierType:
Voltage Feedback
NumberofCircuits:
2
OutputType:
-
SlewRate:
350V/µs
GainBandwidthProduct:
50 MHz
-3dbBandwidth:
50 MHz
Current-InputBias:
3.3 µA
Voltage-InputOffset:
500 µV
Current-Supply:
6.6mA (x2 Channels)
Current-Output/Channel:
50 mA
Voltage-SupplySpan(Min):
5 V
Voltage-SupplySpan(Max):
36 V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount

AD826ARZ this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AD826ARZ price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AD826ARZ to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AD826ARZ information

Views：

AD826ARZ Typical application Circuitry

AD826ARZ

The AD826ARZ is a high-speed dual operational amplifier from Analog Devices. It is particularly noted for its high output drive capability and low input voltage noise. Here's a step-by-step guide to connecting this integrated circuit (IC) within your circuit:

1. VCC+ (Pin 8): This is the positive supply voltage pin. For the AD826ARZ, this can be any value from ±5V to ±15V, depending on your application. To ensure stability, it is recommended to decouple this pin with a capacitor to the circuit ground, typically around 0.1 of.

2. VCC- (Pin 4): This is the negative supply voltage pin, it should be connected to the negative rail of your power supply. The same voltage supply rules apply as with the VCC+ pin. This pin should also be decoupled to ground with a capacitor.

3. INPUTS - INA- (Pin 2), INA+ (Pin 3), INB- (Pin 5), INB+ (Pin 6): These are the inverting and non-inverting inputs for the two operational amplifiers. Depending on your application, you may connect these pins to the signals you want to amplify, subtract, or otherwise manipulate.

4. OUTPUTS - OUT (Pin 1), OUT (Pin 7): These are the output pins for the two operational amplifiers. You can connect these to the subsequent stages of your circuit. For the AD826ARZ, these are capable of driving significant loads, up to about 50 MA.

5. GND: Although there isn't a specific ground pin on the AD826ARZ, it's important to properly ground your circuit. Connect your circuit's common ground to the ground reference of your power source.

The AD826ARZ is a powerful component for many applications, ranging from video and imaging equipment to active filters and general signal conditioning tasks. Please consult the data sheet for additional information including specific electrical characteristics, operational ranges, and potential applications.
