Analog Devices Inc. AD824AR-14-REEL7

Part No.:: AD824AR-14-REEL7

Manufacturer:: Analog Devices Inc.

Package:: 14-SOIC (0.154, 3.90mm Width)

Datasheet:: AD824AR-14-REEL7.pdf

Description:: IC OPAMP JFET 4 CIRCUIT 14SOIC

In Stock:: 2790

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD824AR-14-REEL7 Specifications

Package/Case:
14-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
AmplifierType:
J-FET
NumberofCircuits:
4
OutputType:
Rail-to-Rail
SlewRate:
2V/µs
GainBandwidthProduct:
2 MHz
-3dbBandwidth:
2 MHz
Current-InputBias:
4 pA
Voltage-InputOffset:
500 µV
Current-Supply:
560µA (x4 Channels)
Current-Output/Channel:
12 mA
Voltage-SupplySpan(Min):
3 V
Voltage-SupplySpan(Max):
30 V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
