Analog Devices Inc. AD823ARZ

Part No.:: AD823ARZ

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:

Description:: IC OPAMP JFET 2 CIRCUIT 8SOIC

In Stock:: 11245

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD823ARZ Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tube
Series:
-
ProductStatus:
Active
AmplifierType:
J-FET
NumberofCircuits:
2
OutputType:
Rail-to-Rail
SlewRate:
25V/µs
GainBandwidthProduct:
-
-3dbBandwidth:
16 MHz
Current-InputBias:
5 pA
Voltage-InputOffset:
700 µV
Current-Supply:
7mA
Current-Output/Channel:
17 mA
Voltage-SupplySpan(Min):
3 V
Voltage-SupplySpan(Max):
36 V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount

AD823ARZ this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AD823ARZ price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AD823ARZ to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AD823ARZ information

Views：

AD823ARZ Typical application Circuitry

The AD823ARZ is a high-performance, dual operational amplifier known for its rail-to-rail performance and low power characteristics. It is widely favored for its versatility in both AC and DC operations.

Prevalent Use Cases:

1. Audio Processing

2. Active Filters

3. Charge Amplification for Photodiodes

4. Signal Conditioning

5. Battery-powered devices

Core Specifications:

- Rail-to-Rail Output: The AD823ARZ can operate very close to the supply rails, maximizing the dynamic range.

- Dual Amplifiers: The IC houses two independent operational amplifiers.

- Low Power Consumption: With its minimal current draw, it's an excellent fit for portable or battery-driven applications.

- Broad Bandwidth: The AD823ARZ is equipped with a wide operational bandwidth, accommodating a variety of signal frequencies.

Application Example: Audio Signal Amplification:

1. Power Connections:

- Connect the V+ pin (Pin 8) of the AD823ARZ to a positive power source, typically within +3V to +12V.

- The V- pin (Pin 4) should be connected to the system's ground.

2. Input Configuration:

- Your audio input source should be connected to the non-inverting input pin, IN+ (Pin 3) of one of the operational amplifiers in the AD823ARZ.

- The inverting input, IN- (Pin 2), is used for feedback and will connect to the output via a resistor.

3. Feedback Mechanism:

- Introduce a feedback resistor (Rf) from the OUT pin (Pin 1) to the IN- pin (Pin 2). This determines the gain of the amplifier.

- A second resistor (R1) connects from the IN- pin (Pin 2) to the ground. The gain of the amplifier can be calculated as: Gain = 1 + (Rf/R1).

4. Output Signal:

- Extract your amplified audio signal from the OUT pin (Pin 1). This can be fed into another stage of processing or directly to a speaker or recording device.

Crucial Design Points:

1. Component Quality: Especially in audio applications, component quality can directly impact sound quality. Utilize high-grade capacitors and resistors for optimal performance with the AD823ARZ.

2. Power Supply Decoupling: Incorporate decoupling capacitors close to the power pins to prevent unwanted oscillations or noise.

3. Thermal Considerations: Ensure adequate ventilation or heat sinking if the chip is driven hard, even though it's a low-power device.

4. Layout: Keep input and feedback paths short to minimize interference and noise pick-up.

In essence, the AD823ARZ stands out as a potent operational amplifier, suitable for a broad spectrum of applications. Proper circuit design, component choice, and attention to layout intricacies will guarantee you harness its full potential.
