Analog Devices Inc. AD822ARMZ

Part No.:: AD822ARMZ

Manufacturer:: Analog Devices Inc.

Package:: 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)

Datasheet:

Description:: IC OPAMP GP 2 CIRCUIT 8MSOP

In Stock:: 2762

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD822ARMZ Specifications

Package/Case:
8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Packaging:
Tube
Series:
-
ProductStatus:
Active
AmplifierType:
General Purpose
NumberofCircuits:
2
OutputType:
Rail-to-Rail
SlewRate:
3V/µs
GainBandwidthProduct:
1.9 MHz
-3dbBandwidth:
1.9 MHz
Current-InputBias:
2 pA
Voltage-InputOffset:
400 µV
Current-Supply:
1.24mA
Current-Output/Channel:
20 mA
Voltage-SupplySpan(Min):
5 V
Voltage-SupplySpan(Max):
30 V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
