Analog Devices Inc. AD817ARZ

Part No.:: AD817ARZ

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:

Description:: IC OPAMP GP 1 CIRCUIT 8SOIC

In Stock:: 3775

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD817ARZ Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tube
Series:
-
ProductStatus:
Active
AmplifierType:
General Purpose
NumberofCircuits:
1
OutputType:
-
SlewRate:
350V/µs
GainBandwidthProduct:
50 MHz
-3dbBandwidth:
50 MHz
Current-InputBias:
3.3 µA
Voltage-InputOffset:
500 µV
Current-Supply:
7mA
Current-Output/Channel:
50 mA
Voltage-SupplySpan(Min):
5 V
Voltage-SupplySpan(Max):
36 V
OperatingTemperature:
-45°C ~ 85°C
MountingType:
Surface Mount

AD817ARZ this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AD817ARZ price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AD817ARZ to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AD817ARZ information

Views：

AD817ARZ Typical application Circuitry

AD817ARZ

The AD817ARZ is a high speed, high performance operational amplifier known for its wide bandwidth and high output current drive capability. It is designed to operate from a single supply as well as dual supplies, making it highly versatile for a wide range of applications, including driving cables, active filters, and buffering for ADCs.

Application Scenario:

One of the key applications of the AD817ARZ is in driving ADC (Analog-to-Digital Converter) inputs in data acquisition systems, where its high speed and ability to drive capacitive loads are crucial for accurate and rapid signal conversion.

Parameter Features:

The AD817ARZ features include a wide bandwidth (up to 50MHz), high slew rate, ability to drive large capacitive loads, and operate from single or dual power supplies. It is hence a great option for applications involving high-speed signal processing.

Example of a Specific Circuit Connection: ADC Input Driver

1. Signal Input Connection:

- Input Coupling: Connect the signal source to the non-inverting input (pin 3) of the AD817ARZ. If necessary, use a coupling capacitor to block DC components.

2. Power Supply Configuration:

- Dual Supply Operation: Connect a +15V supply to the V+ pin (pin 7) and a -15V supply to the V- pin (pin 4) to provide the operational amplifier with a dual power supply. This setup ensures a wide output swing and maximizes the dynamic range available to the ADC.

3. Output to ADC:

- Driving the ADC: Connect the output of the AD817ARZ (pin 6) directly to the input of an ADC. Implement a series resistor if needed to limit the current into the ADC's input.

4. Setting the Gain and Feedback Loop:

- Gain Configuration: To establish the required gain, place a feedback resistor between the inverting input (pin 2) and the output (pin 6). Add a resistor from the inverting input to ground to complete the feedback network and define the closed-loop gain of the amplifier.

Circuit Design Considerations:

- Power Supply Decoupling: Use decoupling capacitors close to the power supply pins of the AD817ARZ to reduce noise and ripple from the power supply, which is critical for high-speed and precision applications.

- Load Drive Capability: Consider the capacitive load presented by the ADC and ensure that it is within the drive capability of the AD817ARZ to prevent instability or slew rate limitations.

- Signal Bandwidth: Ensure that the bandwidth of the AD817ARZ and the designed circuit matches the frequency requirements of the signal to be acquired, optimizing the fidelity of the signal transmission to the ADC.

- Thermal Management: Given the high-speed nature of the AD817ARZ, it may dissipate significant power under certain conditions. Make sure there is enough ventilation or heat sinking to keep the operational amplifier's temperature within acceptable bounds.

By carefully addressing these considerations and leveraging the high-speed, high-drive capabilities of the AD817ARZ, designers can create efficient ADC driving solutions in data acquisition systems, ensuring accurate and fast signal processing.
