Analog Devices Inc. AD8131ARZ-REEL7

Part No.:: AD8131ARZ-REEL7

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: AD8131ARZ-REEL7.pdf

Description:: IC OPAMP DIFF 1 CIRCUIT 8SOIC

In Stock:: 440

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD8131ARZ-REEL7 Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
AmplifierType:
Differential
NumberofCircuits:
1
OutputType:
Differential
SlewRate:
2000V/µs
GainBandwidthProduct:
-
-3dbBandwidth:
400 MHz
Current-InputBias:
500 nA
Voltage-InputOffset:
1.5 mV
Current-Supply:
11.5mA
Current-Output/Channel:
60 mA
Voltage-SupplySpan(Min):
2.8 V
Voltage-SupplySpan(Max):
11 V
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
