Name: AD8066ARZ-RL
Brand: Analog Devices Inc.
SKU: AD8066ARZ-RL
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc. AD8066ARZ-RL

Part No.:: AD8066ARZ-RL

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: AD8066ARZ-RL.pdf

Description:: IC VOLTAGE FEEDBACK 2 CIRC 8SOIC

In Stock:: 2155

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD8066ARZ-RL Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Bulk
Series:
FastFET™
ProductStatus:
Active
AmplifierType:
Voltage Feedback
NumberofCircuits:
2
OutputType:
Rail-to-Rail
SlewRate:
180V/µs
GainBandwidthProduct:
-
-3dbBandwidth:
155 MHz
Current-InputBias:
3 pA
Voltage-InputOffset:
400 µV
Current-Supply:
6.6mA (x2 Channels)
Current-Output/Channel:
30 mA
Voltage-SupplySpan(Min):
5 V
Voltage-SupplySpan(Max):
24 V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
