Analog Devices Inc. AD8065ARZ-REEL7

Part No.:: AD8065ARZ-REEL7

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: AD8065ARZ-REEL7.pdf

Description:: IC VOLTAGE FEEDBACK 1 CIRC 8SOIC

In Stock:: 13068

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD8065ARZ-REEL7 Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
FastFET™
ProductStatus:
Active
AmplifierType:
Voltage Feedback
NumberofCircuits:
1
OutputType:
Rail-to-Rail
SlewRate:
180V/µs
GainBandwidthProduct:
-
-3dbBandwidth:
145 MHz
Current-InputBias:
3 pA
Voltage-InputOffset:
400 µV
Current-Supply:
6.6mA
Current-Output/Channel:
30 mA
Voltage-SupplySpan(Min):
5 V
Voltage-SupplySpan(Max):
24 V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
