Name: AD8042ARZ-REEL7
Brand: Analog Devices Inc.
SKU: AD8042ARZ-REEL7
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc. AD8042ARZ-REEL7

Part No.:: AD8042ARZ-REEL7

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:

Description:: IC VOLTAGE FEEDBACK 2 CIRC 8SOIC

In Stock:: 1492

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD8042ARZ-REEL7 Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
AmplifierType:
Voltage Feedback
NumberofCircuits:
2
OutputType:
Rail-to-Rail
SlewRate:
225V/µs
GainBandwidthProduct:
90 MHz
-3dbBandwidth:
170 MHz
Current-InputBias:
1.2 µA
Voltage-InputOffset:
3 mV
Current-Supply:
6mA (x2 Channels)
Current-Output/Channel:
50 mA
Voltage-SupplySpan(Min):
3 V
Voltage-SupplySpan(Max):
12 V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
