Analog Devices Inc. AD8041ARZ-REEL

Part No.:: AD8041ARZ-REEL

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:

Description:: IC VOLTAGE FEEDBACK 1 CIRC 8SOIC

In Stock:: 3241

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD8041ARZ-REEL Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Bulk
Series:
-
ProductStatus:
Active
AmplifierType:
Voltage Feedback
NumberofCircuits:
1
OutputType:
Rail-to-Rail
SlewRate:
170V/µs
GainBandwidthProduct:
-
-3dbBandwidth:
170 MHz
Current-InputBias:
1.2 µA
Voltage-InputOffset:
2 mV
Current-Supply:
5.8mA
Current-Output/Channel:
50 mA
Voltage-SupplySpan(Min):
3 V
Voltage-SupplySpan(Max):
12 V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
