Analog Devices Inc. AD8027ARTZ-REEL

Part No.:: AD8027ARTZ-REEL

Manufacturer:: Analog Devices Inc.

Package:: SOT-23-6

Datasheet:

Description:: IC OPAMP VFB 1 CIRCUIT SOT23-6

In Stock:: 2194

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD8027ARTZ-REEL Specifications

Package/Case:
SOT-23-6
Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
AmplifierType:
Voltage Feedback
NumberofCircuits:
1
OutputType:
Rail-to-Rail
SlewRate:
100V/µs
GainBandwidthProduct:
-
-3dbBandwidth:
190 MHz
Current-InputBias:
4 µA
Voltage-InputOffset:
200 µV
Current-Supply:
6.5mA
Current-Output/Channel:
120 mA
Voltage-SupplySpan(Min):
2.7 V
Voltage-SupplySpan(Max):
12 V
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount

AD8027ARTZ-REEL this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AD8027ARTZ-REEL price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AD8027ARTZ-REEL to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AD8027ARTZ-REEL information

Views：

AD8027ARTZ-REEL Typical application Circuitry

AD8027ARTZ-REEL

The AD8027ARTZ-REEL is a high-performance, low-power, rail-to-rail input/output voltage feedback amplifier. Its design is optimized for single-supply operations, making it an ideal choice for battery-powered applications, as well as in systems where power efficiency is crucial.

Application Scenarios

The AD8027ARTZ-REEL is versatile and finds its use in various scenarios:

- Portable and battery-powered devices due to its low power consumption

- ADC driver circuits, where its rail-to-rail input/output capability ensures maximum dynamic range

- Active filters and sensor signal conditioning, benefiting from its low noise and high precision

- General-purpose high-speed amplification where power efficiency and space are critical

Parameter Features

Key features of the AD8027ARTZ-REEL include:

- Rail-to-rail input and output, enabling full use of the power supply range

- Low input bias current and low offset voltage, ensuring high accuracy

- High slew rate and wide bandwidth for fast signal processing

- Operation from a wide supply voltage range (+2.7V to +12V), accommodating various power supply requirements

Example Application Scenario: ADC Driver Circuit

Here's a detailed circuit design using the AD8027ARTZ-REEL to drive an ADC:

Power Supply and Grounding

First, the AD8027ARTZ-REEL is powered by a single supply voltage, typically 5V, connected to the V+ pin (pin 5), and the ground is connected to the GND pin (pin 4). This configuration provides the operational voltage for the amplifier.

Input Signal Connection

Second, the analog input signal to be digitized is connected to the non-inverting input (IN+, pin 3) of the AD8027ARTZ-REEL. If necessary, a biasing network can be used to set the DC level of the input signal within the rail-to-rail range of the amplifier.

Feedback Loop for Gain Setting

Third, a feedback resistor (Rf) is placed between the output (OUT, pin 6) and the inverting input (IN-, pin 2) to set the gain of the amplifier. A resistor (Rg) is also connected from IN- to ground. The gain of the amplifier is determined by the ratio of Rf to Rg, allowing for precise amplification of the input signal.

Output to ADC Connection

Fourth, the output of the AD8027ARTZ-REEL (OUT, pin 6) is directly connected to the input of the ADC. This setup ensures that the amplified signal is within the ADC's input range, maximizing the ADC's dynamic range.

Bypass Capacitance for Power Stability

Lastly, it's essential to place a bypass capacitor near the V+ pin (pin 5) to filter any noise from the power supply and ensure stable operation of the AD8027ARTZ-REEL.

Design Considerations

When designing circuits with the AD8027ARTZ-REEL, several factors should be carefully considered:

- Power Supply Quality: A clean and stable power supply is crucial for minimizing noise and ensuring the accuracy of the signal processing.

- Impedance Matching: Proper matching of the amplifier's output to the ADC's input impedance is important to prevent signal reflection and distortion.

- Thermal Management: Although the AD8027ARTZ-REEL is designed for low power consumption, attention to thermal management is still necessary in designs pushing the operational limits of the device.

- PCB Layout: Careful PCB layout, including short and direct signal paths and proper grounding, is key to maintaining signal integrity and minimizing interference.

By addressing these considerations and following the detailed design steps, the AD8027ARTZ-REEL can be effectively used to create efficient, high-performance ADC driver circuits, enabling precise and reliable digitization of analog signals in a wide range of applications.
