Analog Devices Inc. AD7896ARZ-REEL

Part No.:: AD7896ARZ-REEL

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: AD7896ARZ-REEL.pdf

Description:: IC ADC 12BIT SAR 8SOIC

In Stock:: 2155

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7896ARZ-REEL Specifications

Packaging:
Tape & Reel (TR),Bulk
Series:
-
Product Status:
Active
Number of Bits:
12
Sampling Rate(PerSecond):
100k
Number of Inputs:
1
Input Type:
Single Ended
Data Interface:
SPI
Configuration:
S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
Supply
Voltage-Supply Analog:
2.7V ~ 5.5V
Voltage-Supply Digital:
2.7V ~ 5.5V
Features:
-
Operating Temperature:
-40°C ~ 85°C
