Analog Devices Inc. AD7894BRZ-10REEL

Part No.:: AD7894BRZ-10REEL

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:

Description:: IC ADC 14BIT SAR 8SOIC

In Stock:: 3076

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7894BRZ-10REEL Specifications

Packaging:
Tape & Reel (TR)
Series:
-
Product Status:
Obsolete
Number of Bits:
14
Sampling Rate(PerSecond):
200k
Number of Inputs:
1
Input Type:
Single Ended
Data Interface:
SPI
Configuration:
S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
External
Voltage-Supply Analog:
5V
Voltage-Supply Digital:
5V
Features:
-
Operating Temperature:
-40°C ~ 85°C
