Analog Devices Inc. AD7892BR-3 REEL

Part No.:: AD7892BR-3 REEL

Manufacturer:: Analog Devices Inc.

Package:: 24-SOIC (0.295, 7.50mm Width)

Datasheet:: AD7892BR-3 REEL.pdf

Description:: AD7892BR-3 REEL

In Stock:: 2028

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7892BR-3 REEL Specifications

Packaging:
Bulk
Series:
AD7892
Product Status:
Active
Number of Bits:
12
Sampling Rate(PerSecond):
600k
Number of Inputs:
2
Input Type:
Single Ended
Data Interface:
SPI, Parallel
Configuration:
S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
External, Internal
Voltage-Supply Analog:
5V
Voltage-Supply Digital:
5V
Features:
-
Operating Temperature:
-40°C ~ 85°C
