Analog Devices Inc. AD7888ARZ

Part No.:: AD7888ARZ

Manufacturer:: Analog Devices Inc.

Package:: 16-SOIC (0.154, 3.90mm Width)

Datasheet:: AD7888ARZ.pdf

Description:: IC ADC 12BIT SAR 16SOIC

In Stock:: 2843

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7888ARZ Specifications

Packaging:
Tube
Series:
-
Product Status:
Active
Number of Bits:
12
Sampling Rate(PerSecond):
125k
Number of Inputs:
8
Input Type:
Single Ended
Data Interface:
SPI, DSP
Configuration:
MUX-S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
External, Internal
Voltage-Supply Analog:
2.7V ~ 5.25V
Voltage-Supply Digital:
2.7V ~ 5.25V
Features:
-
Operating Temperature:
-40°C ~ 105°C
