Name: AD7767BRUZ-2
Brand: Analog Devices Inc.
SKU: AD7767BRUZ-2
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc. AD7767BRUZ-2

Part No.:: AD7767BRUZ-2

Manufacturer:: Analog Devices Inc.

Package:: 16-TSSOP (0.173, 4.40mm Width)

Datasheet:

Description:: IC ADC 24BIT SAR 16TSSOP

In Stock:: 2229

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7767BRUZ-2 Specifications

Packaging:
Bulk,Tube
Series:
-
Product Status:
Active
Number of Bits:
24
Sampling Rate(PerSecond):
32k
Number of Inputs:
1
Input Type:
Differential
Data Interface:
SPI
Configuration:
ADC
Ratio-S/H:ADC:
-
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
External
Voltage-Supply Analog:
2.5V
Voltage-Supply Digital:
2.5V
Features:
-
Operating Temperature:
-40°C ~ 105°C
