Analog Devices Inc. AD7678ASTZ

Part No.:: AD7678ASTZ

Manufacturer:: Analog Devices Inc.

Package:: 48-LQFP

Datasheet:: AD7678ASTZ.pdf

Description:: IC ADC 18BIT SAR 48LQFP

In Stock:: 3029

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7678ASTZ Specifications

Packaging:
Tray
Series:
PulSAR®
Product Status:
Active
Number of Bits:
18
Sampling Rate(PerSecond):
100k
Number of Inputs:
1
Input Type:
Differential
Data Interface:
SPI, Parallel, DSP
Configuration:
S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
External, Internal
Voltage-Supply Analog:
5V
Voltage-Supply Digital:
5V
Features:
-
Operating Temperature:
-40°C ~ 85°C

AD7678ASTZ this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AD7678ASTZ price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AD7678ASTZ to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AD7678ASTZ information

Views：

AD7678ASTZ Typical application Circuitry Schematics

Analog Devices' AD7678ASTZ is a high-precision, quick analog-to-digital converter (ADC). This ADC can be used in a variety of applications, ranging from industrial control to medical imaging and scientific instruments. When designing an application circuit for the AD7678ASTZ, the following things should be considered:

1. Power Supply: The AD7678ASTZ operates from a +5V power supply for the analog components and a separate supply, ranging from +2.7V to +5.5V, for the digital interface. These power pins (AVDD and DVDD) must be connected to the power supply rails through decoupling capacitors to maintain signal integrity and stability.
2. Reference Voltage: The ADC requires a reference voltage (REF) to perform conversions. The AD7678ASTZ has an internal 2.5V reference, but you can also provide an external reference through the REFIN/OUT pin if your application requires a different reference voltage.
3. Analog Input: The AD7678ASTZ has a fully differential analog input. Your analog signal should be connected to the VIN+ and VIN- pins. Make sure that your input signal voltage does not exceed the ADC's input voltage range to avoid damaging the device.
4. Digital Outputs: The conversion result is available on the digital output pins (DB[15:0]). These pins would typically be interfaced with a microcontroller or other digital logic circuitry in your system.
5. Control Signals: Several control signals are available for managing the conversion process, such as the CNVST pin for initiating a conversion, the BUSY pin for indicating when a conversion is taking place, and the RD pin for reading the conversion result.
6. Digital Interface: The AD7678ASTZ supports a flexible digital interface, including a parallel and serial mode, which can be selected via the PD1 and PD0 pins.
Keep in mind that this is a condensed summary of the AD7678ASTZ application circuit. For a detailed description of how to integrate this ADC into your specific application, you should consult the AD7678ASTZ's datasheet and any relevant application notes provided by Analog Devices.
