Analog Devices Inc. AD7631BSTZ

Part No.:: AD7631BSTZ

Manufacturer:: Analog Devices Inc.

Package:: 48-LQFP

Datasheet:: AD7631BSTZ.pdf

Description:: IC ADC 18BIT SAR 48LQFP

In Stock:: 2442

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7631BSTZ Specifications

Packaging:
Bulk,Tray
Series:
PulSAR®
Product Status:
Active
Number of Bits:
18
Sampling Rate(PerSecond):
250k
Number of Inputs:
1
Input Type:
Differential
Data Interface:
SPI, Parallel, DSP
Configuration:
S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
External, Internal
Voltage-Supply Analog:
5V
Voltage-Supply Digital:
5V
Features:
-
Operating Temperature:
-40°C ~ 85°C
