Analog Devices Inc. AD7626BCPZ

Part No.:: AD7626BCPZ

Manufacturer:: Analog Devices Inc.

Package:: 32-WFQFN Exposed Pad, CSP

Datasheet:: AD7626BCPZ.pdf

Description:: IC ADC 16BIT SAR 32LFCSP

In Stock:: 3947

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7626BCPZ Specifications

Packaging:
Tray
Series:
PulSAR®
Product Status:
Active
Number of Bits:
16
Sampling Rate(PerSecond):
10M
Number of Inputs:
1
Input Type:
Differential
Data Interface:
LVDS - Serial
Configuration:
ADC
Ratio-S/H:ADC:
-
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
External, Internal
Voltage-Supply Analog:
5V
Voltage-Supply Digital:
2.37V ~ 2.63V
Features:
-
Operating Temperature:
-40°C ~ 85°C
