Analog Devices Inc. AD7606C-16BSTZ-RL

Part No.:: AD7606C-16BSTZ-RL

Manufacturer:: Analog Devices Inc.

Package:: 64-LQFP

Datasheet:: AD7606C-16BSTZ-RL.pdf

Description:: IC ADC 16BIT SAR 64LQFP

In Stock:: 2328

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7606C-16BSTZ-RL Specifications

Packaging:
Tape & Reel (TR)
Series:
-
Product Status:
Active
Number of Bits:
16
Sampling Rate(PerSecond):
1M
Number of Inputs:
8
Input Type:
Differential, Single Ended
Data Interface:
Serial, SPI, Parallel
Configuration:
PGA-ADC
Ratio-S/H:ADC:
0:1
Number of A/D Converters:
8
Architecture:
SAR
Reference Type:
External, Internal
Voltage-Supply Analog:
4.75V ~ 5.25V
Voltage-Supply Digital:
1.71V ~ 5.25V
Features:
PGA, Simultaneous Sampling, True Bipolar, Temperature Sensor
Operating Temperature:
-40°C ~ 125°C
