The AD736JRZ-R7 is suitable for:
- Accurate RMS measurement in audio equipment
- Power monitoring in industrial control systems
- Precision signal processing in instrumentation
- Battery-powered and portable devices due to its low power consumption
Parameter Features
Key features of the AD736JRZ-R7 include:
- True RMS-to-DC conversion with a wide bandwidth up to 200 kHz
- Low power consumption, ideal for battery-operated devices
- Single-ended input with a full-scale input range of 200 mV
- Capable of operating from a single +5V supply or dual supplies
- High accuracy and temperature stability
Example Application Scenario: Power Monitoring in Industrial Control Systems
Here's a detailed design using the AD736JRZ-R7 for power monitoring in an industrial control system:
Power Supply Connection
Firstly, connect a +5V power source to the V+ pin (pin 8) of the AD736JRZ-R7 for single-supply operation. Connect the V- pin (pin 5) to the system ground. For noise-sensitive applications, consider using a linear regulator to ensure a clean supply.
Input Signal Conditioning
Secondly, if measuring RMS values of voltages higher than 200 mV, incorporate an external resistor divider network to scale the voltage to the INPUT pin (pin 6). To keep accuracy, make sure the resistors are accurate and have a low temperature coefficient.
Filtering of Output
Thirdly, to filter the DC output, attach an output capacitor between the OUTPUT pin (pin 2) and ground.
A value of 1 µF is typically used, but this may vary based on the desired response time and noise filtering requirements.
Bypass Capacitor for Stability
Fourthly, add a 0.1 µF bypass capacitor close to the V+ pin (pin 8) and ground. This capacitor contributes to the stable operation of the AD736JRZ-R7 by filtering out high-frequency noise from the power supply.
Reference Voltage
Lastly, for applications requiring enhanced accuracy beyond the internal bandgap reference, an external precision reference can be connected to the REF IN pin (pin 1). This setup allows for calibration and improved measurement accuracy across temperature variations.
Design Considerations
When designing with the AD736JRZ-R7, it's essential to consider:
- Input Signal Range: Properly scale the input signal to fit within the ADC's range while maintaining signal integrity.
- Power Supply Quality: Use a clean and stable power supply to minimize noise, enhancing the accuracy of RMS measurements.
- Thermal Management: Although the AD736JRZ-R7 is a low-power device, in a densely packed PCB, heat dissipation should be considered.
- PCB Layout: Minimize the length of high-impedance paths and separate analog and digital sections to reduce noise coupling.
Incorporating the AD736JRZ-R7 in a circuit for power monitoring within industrial control systems allows for precise RMS measurement of various signal types, ensuring accurate and reliable monitoring of power parameters critical for system performance and safety.
