Analog Devices Inc. AD637ARZ

Part No.:: AD637ARZ

Manufacturer:: Analog Devices Inc.

Package:: 16-SOIC (0.295, 7.50mm Width)

Datasheet:: AD637ARZ.pdf

Description:: IC RMS TO DC CONVERTER 16SOIC

In Stock:: 3562

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD637ARZ Specifications

Packaging:
Tube
Series:
-
ProductStatus:
Active
Current-Supply:
2.2 mA
Voltage-Supply:
±3V ~ 18V
MountingType:
Surface Mount
