Name: AD7356BRUZ-500RL7
Brand: Analog Devices Inc.
SKU: AD7356BRUZ-500RL7
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc. AD7356BRUZ-500RL7

Part No.:: AD7356BRUZ-500RL7

Manufacturer:: Analog Devices Inc.

Package:: 16-TSSOP (0.173, 4.40mm Width)

Datasheet:

Description:: IC ADC 12BIT SAR 16TSSOP

In Stock:: 3202

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7356BRUZ-500RL7 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
Product Status:
Active
Number of Bits:
12
Sampling Rate(PerSecond):
5M
Number of Inputs:
2
Input Type:
Differential
Data Interface:
SPI, DSP
Configuration:
S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
2
Architecture:
SAR
Reference Type:
External, Internal
Voltage-Supply Analog:
2.25V ~ 2.75V
Voltage-Supply Digital:
2.25V ~ 2.75V
Features:
Simultaneous Sampling
Operating Temperature:
-40°C ~ 85°C
