Analog Devices Inc. AD7352BRUZ-RL

Part No.:: AD7352BRUZ-RL

Manufacturer:: Analog Devices Inc.

Package:: 16-TSSOP (0.173, 4.40mm Width)

Datasheet:: AD7352BRUZ-RL.pdf

Description:: IC ADC 12BIT SAR 16TSSOP

In Stock:: 2855

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7352BRUZ-RL Specifications

Packaging:
Tape & Reel (TR)
Series:
-
Product Status:
Active
Number of Bits:
12
Sampling Rate(PerSecond):
3M
Number of Inputs:
2
Input Type:
Differential
Data Interface:
SPI, DSP
Configuration:
S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
2
Architecture:
SAR
Reference Type:
External, Internal
Voltage-Supply Analog:
2.25V ~ 2.75V
Voltage-Supply Digital:
2.25V ~ 2.75V
Features:
Simultaneous Sampling
Operating Temperature:
-40°C ~ 85°C
