Analog Devices Inc. AD7321BRUZ

Part No.:: AD7321BRUZ

Manufacturer:: Analog Devices Inc.

Package:: 14-TSSOP (0.173, 4.40mm Width)

Datasheet:

Description:: IC ADC 12BIT SAR 14TSSOP

In Stock:: 2246

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7321BRUZ Specifications

Packaging:
Tube
Series:
iCMOS®
Product Status:
Active
Number of Bits:
12
Sampling Rate(PerSecond):
500k
Number of Inputs:
1, 2
Input Type:
Differential, Pseudo-Differential, Single Ended
Data Interface:
SPI, DSP
Configuration:
MUX-S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
External, Internal
Voltage-Supply Analog:
±12V ~ 16.5V
Voltage-Supply Digital:
2.7V ~ 5.25V
Features:
True Bipolar
Operating Temperature:
-40°C ~ 85°C
