Analog Devices Inc. AD7175-8BCPZ-RL

Part No.:: AD7175-8BCPZ-RL

Manufacturer:: Analog Devices Inc.

Package:: 40-WFQFN Exposed Pad, CSP

Datasheet:: AD7175-8BCPZ-RL.pdf

Description:: IC ADC 24BIT SIGMA-DELTA 40LFCSP

In Stock:: 3562

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7175-8BCPZ-RL Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
Product Status:
Active
Number of Bits:
24
Sampling Rate(PerSecond):
250k
Number of Inputs:
8, 16
Input Type:
Differential, Pseudo-Differential, Single Ended
Data Interface:
SPI, DSP
Configuration:
MUX-ADC
Ratio-S/H:ADC:
-
Number of A/D Converters:
1
Architecture:
Sigma-Delta
Reference Type:
External, Internal
Voltage-Supply Analog:
2V ~ 5.5V
Voltage-Supply Digital:
2V ~ 5.5V
Features:
Temperature Sensor
Operating Temperature:
-40°C ~ 105°C
