Analog Devices Inc. AD7124-4BBCPZ

Part No.:: AD7124-4BBCPZ

Manufacturer:: Analog Devices Inc.

Package:: 32-WFQFN Exposed Pad, CSP

Datasheet:: AD7124-4BBCPZ.pdf

Description:: IC ADC 24BIT SIGMA-DELTA 32LFCSP

In Stock:: 3917

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7124-4BBCPZ Specifications

Packaging:
Tray
Series:
-
Product Status:
Active
Number of Bits:
24
Sampling Rate(PerSecond):
19.2k
Number of Inputs:
4, 7
Input Type:
Differential, Pseudo-Differential, Single Ended
Data Interface:
DSP, MICROWIRE™, QSPI™, and SPI™
Configuration:
MUX-PGA-ADC
Ratio-S/H:ADC:
0:1
Number of A/D Converters:
1
Architecture:
Sigma-Delta
Reference Type:
External, Internal
Voltage-Supply Analog:
2.7V ~ 3.6V, ±1.8V
Voltage-Supply Digital:
1.65V ~ 3.6V
Features:
PGA, Temperature Sensor
Operating Temperature:
-40°C ~ 125°C
