Analog Devices Inc. AD711AQ

Part No.:: AD711AQ

Manufacturer:: Analog Devices Inc.

Package:: 8-CDIP (0.300, 7.62mm)

Datasheet:: AD711AQ.pdf

Description:: IC OPAMP JFET 1 CIRCUIT 8CERDIP

In Stock:: 173

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD711AQ Specifications

Package/Case:
8-CDIP (0.300, 7.62mm)
Packaging:
Bulk,Tube
Series:
-
ProductStatus:
Active
AmplifierType:
J-FET
NumberofCircuits:
1
OutputType:
-
SlewRate:
20V/µs
GainBandwidthProduct:
-
-3dbBandwidth:
4 MHz
Current-InputBias:
15 pA
Voltage-InputOffset:
300 µV
Current-Supply:
2.5mA
Current-Output/Channel:
25 mA
Voltage-SupplySpan(Min):
9 V
Voltage-SupplySpan(Max):
36 V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Through Hole
