Analog Devices Inc. AD603ARZ-REEL

Part No.:: AD603ARZ-REEL

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: AD603ARZ-REEL.pdf

Description:: IC VARIABLE GAIN 1 CIRCUIT 8SOIC

In Stock:: 2944

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD603ARZ-REEL Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
X-AMP®
ProductStatus:
Active
AmplifierType:
Variable Gain
NumberofCircuits:
1
OutputType:
-
SlewRate:
275V/µs
GainBandwidthProduct:
-
-3dbBandwidth:
90 MHz
Current-InputBias:
200 nA
Voltage-InputOffset:
-
Current-Supply:
12.5mA
Current-Output/Channel:
50 mA
Voltage-SupplySpan(Min):
9.5 V
Voltage-SupplySpan(Max):
12.6 V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
