Analog Devices Inc. AD4630-24BBCZ-RL

Part No.:: AD4630-24BBCZ-RL

Manufacturer:: Analog Devices Inc.

Package:: 64-FBGA, CSPBGA

Datasheet:: AD4630-24BBCZ-RL.pdf

Description:: 24-BIT, 2 MSPS, DUAL

In Stock:: 2323

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD4630-24BBCZ-RL Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
Product Status:
Active
Number of Bits:
24
Sampling Rate(PerSecond):
2M
Number of Inputs:
2
Input Type:
Differential
Data Interface:
Serial, SPI
Configuration:
ADC
Ratio-S/H:ADC:
0:2
Number of A/D Converters:
2
Architecture:
SAR
Reference Type:
External, Supply
Voltage-Supply Analog:
1.71V ~ 1.89V, 5.3V ~ 5.5V
Voltage-Supply Digital:
1.71V ~ 1.89V, 5.3V ~ 5.5V
Features:
Simultaneous Sampling
Operating Temperature:
-40°C ~ 125°C
