Analog Devices Inc. AD1938WBSTZ

Part No.:: AD1938WBSTZ

Manufacturer:: Analog Devices Inc.

Package:: 48-LQFP

Datasheet:: AD1938WBSTZ.pdf

Description:: IC CODEC 24BIT 4ADC/8DAC 48LQFP

In Stock:: 3790

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD1938WBSTZ Specifications

Package/Case:
48-LQFP
Packaging:
Tray
Series:
Automotive
ProductStatus:
Active
Type:
General Purpose
DataInterface:
Serial
Resolution(Bits):
24 b
NumberofADCs/DACs:
4 / 8
SigmaDelta:
Yes
S/NRatioADCs/DACs(db)Typ:
94 / 94
DynamicRangeADCs/DACs(db)Typ:
105 / 106
Voltage-SupplyAnalog:
3V ~ 3.6V
Voltage-SupplyDigital:
3V ~ 3.6V
OperatingTemperature:
-40°C ~ 105°C
MountingType:
Surface Mount
