Name: 83948AYI-147LFT
Brand: Renesas Electronics America Inc
SKU: 83948AYI-147LFT
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Renesas Electronics America Inc 83948AYI-147LFT

Part No.:: 83948AYI-147LFT

Manufacturer:: Renesas Electronics America Inc

Package:: 32-LQFP

Datasheet:: 83948AYI-147LFT.pdf

Description:: IC CLK BUFFER 2:12 350MHZ 32TQFP

In Stock:: 3786

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

83948AYI-147LFT Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
Product Status:
Obsolete
Type:
Fanout Buffer (Distribution), Multiplexer
Number of Circuits:
1
Ratio-Input: Output:
2:12
Differential-Input: Output:
Yes/No
Input:
HCSL, LVCMOS, LVDS, LVHSTL, LVPECL, LVTTL, SSTL
Output:
LVCMOS, LVTTL
Frequency-Max:
350 MHz
Voltage-Supply:
2.375V ~ 3.465V
Operating Temperature:
-40°C ~ 85°C
Mounting Type:
Surface Mount
