Microchip Technology ZL30267LDG1

Part No.:: ZL30267LDG1

Manufacturer:: Microchip Technology

Package:: 56-VFQFN Exposed Pad

Datasheet:: ZL30267LDG1.pdf

Description:: IC CLOCK GENERATOR 4:10 56-QFN

In Stock:: 3924

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ZL30267LDG1 Specifications

Package/Case:
56-VFQFN Exposed Pad
Packaging:
Tray
Series:
-
ProductStatus:
Active
Type:
Clock Multiplier, Frequency Synthesizer
PLL:
Yes with Bypass
Input:
CMOS, Crystal
Output:
CMOS, HCSL, HSTL, LVDS, LVPECL
NumberofCircuits:
1
Ratio-Input:Output:
4:10
Differential-Input:Output:
Yes/Yes
Frequency-Max:
156.255MHz
Divider/Multiplier:
Yes/No
Voltage-Supply:
1.71V ~ 3.465V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
