Analog Devices Inc. AD9516-1BCPZ-REEL7

Part No.:: AD9516-1BCPZ-REEL7

Manufacturer:: Analog Devices Inc.

Package:: 64-VFQFN Exposed Pad, CSP

Datasheet:: AD9516-1BCPZ-REEL7.pdf

Description:: IC CLOCK GEN 2.5GHZ VCO 64-LFCSP

In Stock:: 684

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD9516-1BCPZ-REEL7 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AD9516-1BCPZ-REEL7 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AD9516-1BCPZ-REEL7 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

Views：

AD9516-1BCPZ-REEL7 Typical application Circuitry

AD9516-1BCPZ-REEL7

The AD9516-1BCPZ-REEL7 is a highly integrated, multi-output clock distribution IC featuring a PLL (Phase-Locked Loop) with VCO (Voltage-Controlled Oscillator), dividers, phase adjusters, and distribution buffers.

Application Scenario:

A key application of the AD9516-1BCPZ-REEL7 is in high-speed data acquisition systems, where precise timing and synchronization are critical for accurate data capture and processing. In such systems, the AD9516-1BCPZ-REEL7 generates synchronized clock signals for analog-to-digital converters (ADCs), ensuring that data sampling occurs at precise intervals.

Parameter Features:

- Integrated PLL with VCO: Offers excellent frequency stability and low phase noise for critical timing applications.

- Multiple Outputs: Provides up to 14 clock outputs, enabling the synchronization of multiple devices within a system.

- Programmable Dividers and Phase Adjusters: Allows for fine-tuning of output frequencies and phase alignment between clock signals.

- Low Jitter Performance: Ensures high-quality, stable clock signals conducive to maximizing system performance.

Detailed Circuit Connection Example:

For a High-Speed Data Acquisition System, integrating the AD9516-1BCPZ-REEL7 involves the following critical steps:

1. Reference Clock Input: Connect a stable, low-jitter external reference clock to the REF_CLK pin. This clock serves as the baseline for all PLL-generated frequencies within the system.

2. Power Supply Connections: Apply a clean +3.3V power supply to the AVDD and DVDD pins, with appropriate decoupling capacitors placed near these pins to filter out noise, ensuring the stable operation of both analog and digital circuits.

3. PLL Configuration: Connect the VCO output to the PLL input through the feedback path, configuring the PLL for the desired multiplication factor via the feedback dividers to achieve the required output frequencies.

4. Output Clock Distribution: Route the clock outputs (CLK_OUTx pins) to the clock inputs of ADCs and other system components requiring synchronization. Each output can be individually configured for specific frequencies and phases to meet the requirements of each component.

5. Control Interface Setup: Utilize the SPI or I²C interface for device configuration, connecting to the SDIO, SCLK, and CSB pins for SPI (or equivalent pins for I²C). This interface allows for dynamic adjustments to the device settings and real-time system optimization.

Design Considerations:

When designing with the AD9516-1BCPZ-REEL7, several factors must be carefully considered:

- Reference Clock Quality: The quality of the reference clock directly impacts the performance of the PLL and the quality of the output clocks. Use a high-quality, stable reference source to minimize jitter and phase noise.

- Power Supply Noise: Implementing low-noise power supplies and comprehensive decoupling strategies is crucial to maintain signal integrity and minimize jitter in the output clocks.

- Thermal Management: Ensure adequate heat dissipation for the AD9516-1BCPZ-REEL7 and surrounding components, as excessive heat can affect device performance and reliability.

- Signal Routing and Integrity: Pay attention to the layout of clock signal traces, minimizing cross-talk and signal degradation to preserve the quality of the clock signals distributed throughout the system.

Incorporating the AD9516-1BCPZ-REEL7 into high-speed data acquisition systems, with careful attention to these design principles, enables the creation of highly synchronized, low-jitter timing architectures essential for achieving accurate and reliable data capture and processing.

AD9516-1BCPZ-REEL7 information

AD9516-1BCPZ-REEL7 Specifications

Package/Case:
64-VFQFN Exposed Pad, CSP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
Type:
Clock Generator, Fanout Distribution
PLL:
Yes
Input:
Clock
Output:
CMOS, LVDS, LVPECL
NumberofCircuits:
1
Ratio-Input:Output:
1:14
Differential-Input:Output:
Yes/Yes
Frequency-Max:
2.95GHz
Divider/Multiplier:
Yes/No
Voltage-Supply:
3.135V ~ 3.465V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
