Xilinx Inc. XCZU47DR-2FFVG1517I

Part No.:: XCZU47DR-2FFVG1517I

Manufacturer:: Xilinx Inc.

Package:: 1517-BBGA, FCBGA

Datasheet:: XCZU47DR-2FFVG1517I.pdf

Description:: IC ZUP RFSOC A53 FPGA 1517BGA

In Stock:: 2804

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XCZU47DR-2FFVG1517I Specifications

Package/Case:
1517-BBGA, FCBGA
Packaging:
Tray
Series:
Zynq® UltraScale+™ RFSoC
ProductStatus:
Active
Architecture:
MCU, FPGA
CoreProcessor:
Quad ARM® Cortex®-A53 MPCore™ with CoreSight™, Dual ARM®Cortex™-R5 with CoreSight™
FlashSize:
-
RAMSize:
256KB
Peripherals:
DMA, WDT
Connectivity:
CANbus, EBI/EMI, Ethernet, I²C, MMC/SD/SDIO, SPI, UART/USART, USB OTG
Speed:
533MHz, 1.333GHz
PrimaryAttributes:
Zynq®UltraScale+™ FPGA, 930K+ Logic Cells
OperatingTemperature:
-40°C ~ 100°C (TJ)
