Xilinx Inc. XC9572XL-7CS48I

Part No.:: XC9572XL-7CS48I

Manufacturer:: Xilinx Inc.

Package:: 48-FBGA, CSPBGA

Datasheet:: XC9572XL-7CS48I.pdf

Description:: IC CPLD 72MC 7.5NS 48CSBGA

In Stock:: 3690

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC9572XL-7CS48I Specifications

Package/Case:
48-FBGA, CSPBGA
Packaging:
Bulk
Series:
XC9500XL
ProductStatus:
Active
ProgrammableType:
In System Programmable (min 10K program/erase cycles)
DelayTimetpd(1)Max:
7.5 ns
VoltageSupply-Internal:
3V ~ 3.6V
NumberofLogicElements/Blocks:
4
NumberofMacrocells:
72
NumberofGates:
1600
NumberofI/O:
38
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
