Xilinx Inc. XC9572-15PC44I

Part No.:: XC9572-15PC44I

Manufacturer:: Xilinx Inc.

Package:: 44-LCC (J-Lead)

Datasheet:: XC9572-15PC44I.pdf

Description:: IC CPLD 72MC 15NS 44PLCC

In Stock:: 3467

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC9572-15PC44I Specifications

Package/Case:
44-LCC (J-Lead)
Packaging:
Tube
Series:
XC9500
ProductStatus:
Obsolete
ProgrammableType:
In System Programmable (min 10K program/erase cycles)
DelayTimetpd(1)Max:
15 ns
VoltageSupply-Internal:
4.5V ~ 5.5V
NumberofLogicElements/Blocks:
4
NumberofMacrocells:
72
NumberofGates:
1600
NumberofI/O:
34
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
