Xilinx Inc. XC95108-15PC84C

Part No.:: XC95108-15PC84C

Manufacturer:: Xilinx Inc.

Package:: 84-LCC (J-Lead)

Datasheet:: XC95108-15PC84C.pdf

Description:: IC CPLD 108MC 15NS 84PLCC

In Stock:: 2845

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC95108-15PC84C Specifications

Package/Case:
84-LCC (J-Lead)
Packaging:
Tube
Series:
XC9500
ProductStatus:
Obsolete
ProgrammableType:
In System Programmable (min 10K program/erase cycles)
DelayTimetpd(1)Max:
15 ns
VoltageSupply-Internal:
4.75V ~ 5.25V
NumberofLogicElements/Blocks:
6
NumberofMacrocells:
108
NumberofGates:
2400
NumberofI/O:
69
OperatingTemperature:
0°C ~ 70°C (TA)
MountingType:
Surface Mount
