Xilinx Inc. XC95108-10TQ100I

Part No.:: XC95108-10TQ100I

Manufacturer:: Xilinx Inc.

Package:: 100-LQFP

Datasheet:: XC95108-10TQ100I.pdf

Description:: IC CPLD 108MC 10NS 100TQFP

In Stock:: 3242

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC95108-10TQ100I Specifications

Package/Case:
100-LQFP
Packaging:
Tray
Series:
XC9500
ProductStatus:
Obsolete
ProgrammableType:
In System Programmable (min 10K program/erase cycles)
DelayTimetpd(1)Max:
10 ns
VoltageSupply-Internal:
4.5V ~ 5.5V
NumberofLogicElements/Blocks:
6
NumberofMacrocells:
108
NumberofGates:
2400
NumberofI/O:
81
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
