Xilinx Inc. XC7Z020-L1CLG400I

Part No.:: XC7Z020-L1CLG400I

Manufacturer:: Xilinx Inc.

Package:: 400-LFBGA, CSPBGA

Datasheet:: XC7Z020-L1CLG400I.pdf

Description:: IC SOC CORTEX-A9 667MHZ 400BGA

In Stock:: 3649

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC7Z020-L1CLG400I Specifications

Package/Case:
400-LFBGA, CSPBGA
Packaging:
Tray
Series:
Zynq®-7000
ProductStatus:
Active
Architecture:
MCU, FPGA
CoreProcessor:
Dual ARM® Cortex®-A9 MPCore™ with CoreSight™
FlashSize:
-
RAMSize:
256KB
Peripherals:
DMA
Connectivity:
CANbus, EBI/EMI, Ethernet, I²C, MMC/SD/SDIO, SPI, UART/USART, USB OTG
Speed:
667MHz
PrimaryAttributes:
Artix™-7 FPGA, 85K Logic Cells
OperatingTemperature:
-40°C ~ 100°C (TJ)
