Xilinx Inc. XC7S6-1CSGA225I

Part No.:: XC7S6-1CSGA225I

Manufacturer:: Xilinx Inc.

Package:: 225-LFBGA, CSPBGA

Datasheet:: XC7S6-1CSGA225I.pdf

Description:: IC FPGA 100 I/O 225CSBGA

In Stock:: 3287

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC7S6-1CSGA225I Specifications

Package/Case:
225-LFBGA, CSPBGA
Packaging:
Tray
Series:
Spartan®-7
ProductStatus:
Active
NumberofLABs/CLBs:
-
NumberofLogicElements/Cells:
6000
TotalRAMBits:
184320
NumberofI/O:
100
NumberofGates:
-
Voltage-Supply:
0.95V ~ 1.05V
MountingType:
Surface Mount
OperatingTemperature:
-40°C ~ 100°C (TJ)
