Xilinx Inc. XC7S50-2CSGA324I

Part No.:: XC7S50-2CSGA324I

Manufacturer:: Xilinx Inc.

Package:: 324-LFBGA, CSPBGA

Datasheet:: XC7S50-2CSGA324I.pdf

Description:: IC FPGA 210 I/O 324CSBGA

In Stock:: 3387

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC7S50-2CSGA324I Specifications

Package/Case:
324-LFBGA, CSPBGA
Packaging:
Tray
Series:
Spartan®-7
ProductStatus:
Active
NumberofLABs/CLBs:
4075
NumberofLogicElements/Cells:
52160
TotalRAMBits:
2764800
NumberofI/O:
210
NumberofGates:
-
Voltage-Supply:
0.95V ~ 1.05V
MountingType:
Surface Mount
OperatingTemperature:
-40°C ~ 100°C (TJ)
