Xilinx Inc. XC7S50-1FTGB196C

Part No.:: XC7S50-1FTGB196C

Manufacturer:: Xilinx Inc.

Package:: 196-LBGA, CSPBGA

Datasheet:: XC7S50-1FTGB196C.pdf

Description:: IC FPGA 100 I/O 196CSBGA

In Stock:: 2052

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC7S50-1FTGB196C Specifications

Package/Case:
196-LBGA, CSPBGA
Packaging:
Tray
Series:
Spartan®-7
ProductStatus:
Active
NumberofLABs/CLBs:
4075
NumberofLogicElements/Cells:
52160
TotalRAMBits:
2764800
NumberofI/O:
100
NumberofGates:
-
Voltage-Supply:
0.95V ~ 1.05V
MountingType:
Surface Mount
OperatingTemperature:
0°C ~ 85°C (TJ)
