Xilinx Inc. XC7K160T-3FBG484E

Part No.:: XC7K160T-3FBG484E

Manufacturer:: Xilinx Inc.

Package:: 484-BBGA, FCBGA

Datasheet:: XC7K160T-3FBG484E.pdf

Description:: IC FPGA 285 I/O 484FCBGA

In Stock:: 3452

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC7K160T-3FBG484E Specifications

Package/Case:
484-BBGA, FCBGA
Packaging:
Tray
Series:
Kintex®-7
ProductStatus:
Active
NumberofLABs/CLBs:
12675
NumberofLogicElements/Cells:
162240
TotalRAMBits:
11980800
NumberofI/O:
285
NumberofGates:
-
Voltage-Supply:
0.97V ~ 1.03V
MountingType:
Surface Mount
OperatingTemperature:
0°C ~ 100°C (TJ)
