Xilinx Inc. XC7A100T-3CSG324E

Part No.:: XC7A100T-3CSG324E

Manufacturer:: Xilinx Inc.

Package:: 324-LFBGA, CSPBGA

Datasheet:: XC7A100T-3CSG324E.pdf

Description:: IC FPGA 210 I/O 324CSBGA

In Stock:: 3028

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC7A100T-3CSG324E Specifications

Package/Case:
324-LFBGA, CSPBGA
Packaging:
Tray
Series:
Artix-7
ProductStatus:
Active
NumberofLABs/CLBs:
7925
NumberofLogicElements/Cells:
101440
TotalRAMBits:
4976640
NumberofI/O:
210
NumberofGates:
-
Voltage-Supply:
0.95V ~ 1.05V
MountingType:
Surface Mount
OperatingTemperature:
0°C ~ 100°C (TJ)
