Xilinx Inc. XC6SLX25T-3CSG324C

Part No.:: XC6SLX25T-3CSG324C

Manufacturer:: Xilinx Inc.

Package:: 324-LFBGA, CSPBGA

Datasheet:: XC6SLX25T-3CSG324C.pdf

Description:: IC FPGA 190 I/O 324CSBGA

In Stock:: 2129

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC6SLX25T-3CSG324C Specifications

Package/Case:
324-LFBGA, CSPBGA
Packaging:
Tray
Series:
Spartan®-6 LXT
ProductStatus:
Active
NumberofLABs/CLBs:
1879
NumberofLogicElements/Cells:
24051
TotalRAMBits:
958464
NumberofI/O:
190
NumberofGates:
-
Voltage-Supply:
1.14V ~ 1.26V
MountingType:
Surface Mount
OperatingTemperature:
0°C ~ 85°C (TJ)
