Xilinx Inc. XC3SD3400A-4CSG484C

Part No.:: XC3SD3400A-4CSG484C

Manufacturer:: Xilinx Inc.

Package:: 484-FBGA, CSPBGA

Datasheet:: XC3SD3400A-4CSG484C.pdf

Description:: IC FPGA 309 I/O 484CSBGA

In Stock:: 3725

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC3SD3400A-4CSG484C Specifications

Package/Case:
484-FBGA, CSPBGA
Packaging:
Tray
Series:
Spartan®-3A DSP
ProductStatus:
Active
NumberofLABs/CLBs:
5968
NumberofLogicElements/Cells:
53712
TotalRAMBits:
2322432
NumberofI/O:
309
NumberofGates:
3400000
Voltage-Supply:
1.14V ~ 1.26V
MountingType:
Surface Mount
OperatingTemperature:
0°C ~ 85°C (TJ)

XC3SD3400A-4CSG484C this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including XC3SD3400A-4CSG484C price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for XC3SD3400A-4CSG484C to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.
