Xilinx Inc. XC3S700A-4FG400I

Part No.:: XC3S700A-4FG400I

Manufacturer:: Xilinx Inc.

Package:: 400-BGA

Datasheet:: XC3S700A-4FG400I.pdf

Description:: IC FPGA 311 I/O 400FBGA

In Stock:: 3124

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC3S700A-4FG400I Specifications

Package/Case:
400-BGA
Packaging:
Tray
Series:
Spartan®-3A
ProductStatus:
Active
NumberofLABs/CLBs:
1472
NumberofLogicElements/Cells:
13248
TotalRAMBits:
368640
NumberofI/O:
311
NumberofGates:
700000
Voltage-Supply:
1.14V ~ 1.26V
MountingType:
Surface Mount
OperatingTemperature:
-40°C ~ 100°C (TJ)
