Xilinx Inc. XC3S4000-4FGG676C

Part No.:: XC3S4000-4FGG676C

Manufacturer:: Xilinx Inc.

Package:: 676-BGA

Datasheet:: XC3S4000-4FGG676C.pdf

Description:: IC FPGA 489 I/O 676FBGA

In Stock:: 3160

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC3S4000-4FGG676C Specifications

Package/Case:
676-BGA
Packaging:
Tray
Series:
Spartan®-3
ProductStatus:
Active
NumberofLABs/CLBs:
6912
NumberofLogicElements/Cells:
62208
TotalRAMBits:
1769472
NumberofI/O:
489
NumberofGates:
4000000
Voltage-Supply:
1.14V ~ 1.26V
MountingType:
Surface Mount
OperatingTemperature:
0°C ~ 85°C (TJ)

XC3S4000-4FGG676C this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including XC3S4000-4FGG676C price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for XC3S4000-4FGG676C to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.
